A panelized torsion spring metal ceiling system in a variety of blade configurations, achieving an accessible, open reveal linear look installed up to twice as fast as individual blade systems.

Features

• 20 Standard 24" x 96" panels with multiple blades in varying heights, widths, and spacing configurations
• 1" and 2" Wide blades with 4", 6", and 8" heights
• 24" x 96" Torsion spring panels install up to twice as fast as individual blade systems
• Durable, downward accessible system - quickly open a large area with full panel removal
• Mix and match standard panels with alternating blade heights or widths for a custom look
• Smart design – reveals between blades are equidistant panel-to-panel; Panels have a consistent 1/8" reveal end-to-end
• METALWORKS IMMIX panels are part of the SUSTAIN portfolio, and meet the most stringent industry sustainability compliance standards today
• CLEANASSURE family of products – includes disinfectable planks, suspension systems, and trim
• 11 Panels with 70% or more open area to minimize sprinkler install and material cost, achieving a less cluttered finished ceiling with an open aesthetic
• Panels can be field cut; perimeter cut kit and additional end caps are available for a clean, professional finish
• Black acoustical infill panels hide the plenum and achieve up to 0.95 NRC
• Get total noise control and design flexibility with TOTAL ACOUSTICS ceiling panels: NRC + CAC = TOTAL ACOUSTICS
• Aluminum blades with exceptional durability – washable, scrubbable, soil-resistant

Specifications

• Sound Absorption (NRC): 0.40
• % Open Area: 92%
• Fire Performance: Class A
• Light Reflectance: 75%
• Mold/Mildew Resistance: Inherent
• Disinfectability: Fog, Spray, Wipe
• Durability: Soil Resistance, Impact Resistance, Scratch Resistance, Washability, Scrubbability
• Material: Metal
• Surface Finish: Factory-applied polyester paint
• Shape: Rectangle
• Weight: 0.36 lbs/SF
• ASTM Classification: Type: XX, Pattern: C
• Installation Method: Grid (Suspended)
• Accessibility: Yes
• Recycled Content: 16%
• Perforation: M15
• No. of Blades - Spacing: 2 blades - 1" W x 4" H x 11"

16 sq ft/ctn
